Wire EDM

Tuowei Precision provides advanced wire EDM machining, delivering high-precision parts with exceptional accuracy and intricate details.

Custom Wire EDM Machining With TUOWEI

TUOWEI Precision specializes in delivering custom Wire EDM machining services with speed, accuracy, and consistency. Unlike traditional methods, Wire EDM (Electrical Discharge Machining) uses a thin, electrically charged wire and deionized water to precisely cut conductive materials. This makes Wire EDM ideal for creating both simple and highly complex geometries with tight tolerances.

Our facilities are fully certified, holding ISO 9001:2015, ISO 13485:2016, ISO 14001:2015, and IATF 16949:2016, ensuring the highest levels of quality control across every project. With advanced EDM equipment and a team of skilled engineers, we can efficiently produce precision components for industries. Whether you need one-off prototypes or production parts, TUOWEI Precision provides reliable Wire EDM machining services designed to meet your exact specifications.

Cost-Efficient Setup for Complex Profiles

We eliminate costly tooling and reduce machining steps by cutting directly through the part profile, even for enclosed geometries. Just send us your CAD and we’ll convert it to reality.

With multi-wire setups and submerged EDM capabilities, we cut faster and cleaner—even on thick workpieces or mirror-finish requirements.

Wire Cutting EDM Tolerances

Tuowei offers precision wire EDM services suitable for a wide range of part sizes, from intricate micro components to larger, complex assemblies. Our processes ensure consistent accuracy and strict adherence to dimensional standards.

Wire Cutting Service	Tolerance
Standard Wire Cutting	±0.005" (±0.127 mm)
High-Precision Wire Cutting	±0.002" (±0.051 mm)
Wire Cutting for Small Parts	±0.003" (±0.076 mm)
Wire Cutting for Large Parts	±0.010" (±0.254 mm)
Wire Cutting with Complex Features	±0.005" (±0.127 mm) for detailed cuts

Materials for Wire Cutting

Engineers and leading manufacturers trust TUOWEI Precision for fast iterations and durable, high-performance parts. Whether for prototyping or full-scale production, our extensive material selection ensures precision, strength, and reliability for any CNC machining project.

Aluminum

Aluminum 5052
Aluminum 7075 & 7075-T6
Aluminum 6063-T5
Aluminum 7050-T7451
Aluminum MIC-6
Aluminum 6061-T6
Aluminum 2024-T3

Bronze/Brass

Brass C360
Brass 260
C932 M07 Bearing Bronze

Copper

EPT Copper C110

Copper 101

Steel

Alloy Steel 4130

Alloy Steel 4140

ASTM A36, Stainless Steel 15-5

Stainless Steel 17-4

Stainless Steel 18-8

Stainless Steel 303

Stainless Steel 304

Stainless Steel 316/316L

Stainless Steel 416, Stainles Steel 420

Steel 1018

Steel A36

Titanium

Titanium Grade 2

Titanium 6Al-4V

Zinc

Zinc Sheet Alloy 500

Wire Cutting Surface Finishes

For Wire Cutting, here are some surface finishing techniques that work well to finalize the cut parts:

Polishing

Polishing smoothens out the wire-cut edges, improving the overall finish and reducing the possibility of sharp edges.

Electrochemical Deburring

This technique uses an electrolytic process to remove burrs and smooth edges, providing a clean finish without mechanical contact.

Shot Blasting

Shot blasting involves shooting abrasive particles at the surface to create a smooth, uniform texture that removes imperfections from the wire-cut edges.

Micro-Honing

Micro-honing uses fine abrasive tools to polish and smooth the surface, perfect for parts that require tight tolerances.

Passivation

Passivation adds a protective oxide layer to metal surfaces, enhancing resistance to corrosion and improving the longevity of the wire-cut components.

Anodizing

Anodizing enhances the surface hardness and appearance of aluminum and other metals, offering greater protection against wear and corrosion.

Advantages

Advantages of Wire EDM Machining

Wire EDM provides unmatched precision and flexibility, making it ideal for industries requiring complex and high-quality components.

Precision and Accuracy: Wire EDM can produce parts with extremely tight tolerances, often within ±0.0001 inches, which is crucial for applications in aerospace, medical, and tool and die manufacturing.
Complex Geometries: The process allows the creation of intricate shapes, sharp internal corners, and detailed contours that are nearly impossible to achieve with conventional machining methods.
Material Versatility: It can cut through any electrically conductive material, including hardened steels, titanium, and superalloys, without causing stress, distortion, or thermal damage to the part.
Smooth Surface Finishes: Wire EDM delivers exceptionally fine finishes, often as smooth as 16 microinch Ra, minimizing or even eliminating the need for secondary finishing operations.
No Contact Cutting: Since the wire never physically touches the part, the process eliminates mechanical stresses, making it ideal for fragile, delicate, or thin-walled components.

Applications

Applications of Wire Cut Parts

Wire EDM machining provides precision and versatility, enabling high-quality production across various industries.

Aerospace: Wire EDM is used to fabricate components with intricate geometries and extremely tight tolerances, ensuring that parts meet the rigorous safety and performance standards required in the aerospace sector.
Medical Devices:The process enables the manufacture of detailed implants and surgical instruments with unmatched accuracy, guaranteeing the safety, reliability, and functionality of critical medical tools.
Tool and Die Making: Wire EDM is perfect for producing precise molds, dies, and fixtures with exceptionally smooth finishes and exact dimensions, supporting long tool life and high-quality manufacturing.
Automotive: It supports the production of high-precision gears and critical components that require stringent tolerances, improving overall performance and reliability in automotive systems.
Custom Manufacturing: The technique caters to specialized manufacturing needs, such as creating bespoke machinery components or cutting complex parts from exotic and hard-to-machine materials.

Let’s Build What’s Next Together

Partner with TUOWEI to Shape Your Vision

Since the era of rapid prototyping through scalable production, Tuowei Precision helps with your project because of its reliable CNC machining and manufacturing services. Our team collaborates with you to make sure that there is accuracy, consistency, and a smooth execution at all levels.

Begin your project now and start with the first step towards efficient and high quality manufacturing with Tuowei.

Get In Touch With Us!

Prompt response guaranteed within 12 hours

Frequently Asked Questions

Wire Cutting (EDM) Services

What are the main limitations of Wire EDM?

While Wire EDM is precise and versatile, it has some limitations. It can only cut electrically conductive materials, excluding plastics, ceramics, and composites. Cutting speed is slower than some conventional machining methods, especially on very thick materials, which may increase production time. Operating costs can be higher due to the continuous use of wire and dielectric fluid. Machine setup and programming are complex, requiring skilled operators. Achieving the highest surface finishes may require additional passes, further extending machining time.
Can Wire EDM cut very thick materials?

Yes, Wire EDM can cut materials up to 12 inches (300 mm) thick depending on the machine and setup. Using a thin wire electrode to erode the material, it maintains precision without distortion. This capability is essential for large molds, heavy-duty machine components, and aerospace parts, ensuring consistent accuracy in thick, dense materials.
What shapes can Wire EDM create?

Wire EDM can produce highly intricate 2D and 3D geometries, including sharp internal corners, complex contours, and detailed patterns. It can handle thin walls, small holes, and narrow slots with high accuracy. This versatility makes it perfect for aerospace, medical devices, and precision molds or dies where complex and exacting shapes are required.
How precise is Wire EDM?

Wire EDM achieves exceptional precision, with tolerances as tight as ±0.0001 inches (±2.5 microns). The thin wire electrode, guided by advanced CNC controls, allows consistent accuracy across complex and intricate shapes. The process also provides smooth surfaces, often reducing the need for post-processing. This level of precision makes Wire EDM ideal for aerospace components, medical devices, and high-precision tooling.
Can Wire EDM machine hard materials?

Yes, Wire EDM can effectively machine hard materials such as hardened tool steels, titanium, tungsten carbide, and superalloys. Using electrical discharges rather than mechanical force, it eliminates tool wear and material distortion while achieving intricate shapes and tight tolerances. This makes it ideal for aerospace, medical devices, and tool and die industries, ensuring high-quality finishes even in the hardest metals.
What are the types of EDM machining?

There are three main types of EDM processes. Wire EDM uses a thin wire as an electrode to cut intricate shapes and contours in conductive materials with high precision, ideal for aerospace, medical, and electronics components. Sinker EDM (Ram EDM) employs a custom-shaped electrode plunged into the workpiece to create detailed cavities and molds, commonly used in die production and complex part fabrication. Hole-Drilling EDM specializes in creating small, precise holes in hard materials, often used for turbine blade cooling holes or as a preliminary step before wire EDM.
