PETG 3D printing is robust, tough and gaining popularity in fused deposition modeling. But layer lines, flaws, and coarse textures tend to require post-processing. One of the most effective methods to smooth PETG, PLA and other similar filaments is vapor smoothing, which provides your 3D print models with a glossy finish, improved appearance, and closed outside coating.
Surface smoothing of PLA and PETG has been an important technique in the current 3D printing to improve the quality of surfaces. The outermost layer of the plastic gets softened and levels itself through special exposure to the chemical vapour, and the imperfections and layer lines are removed.
We have demonstrated in our experiments that PETG filament is receptive to MEK, ethyl acetate, and dichloromethane vapors, which makes its surfaces perfectly smooth. Vapor smoothing methods in comparison with sanding and polishing methods do not deform the dimensions and lessen the possibility of mechanical properties destruction thereby it is the best post-processing method of a professional quality print.
The main purposes of vapor smoothing PETG include:
This technique is especially useful for PETG prints, which are strong but naturally harder to smooth chemically than ABS or PLA.
PETG vapor smoothing is a chemical post-processing method involving the following steps:
Adequately conducted vapor smoothing enhances aesthetics on the surface and preserves the mechanical properties and dimensional accuracy.
The process works because solvent vapors temporarily soften the outer layer of the plastic without melting it completely. This allows:
Using brush and spray smoothing can target specific areas, ideal for delicate prints where full vapor baths may compromise dimensional accuracy.
Brush and spray techniques are alternatives for intricate 3D printed parts. Benefits include:
This approach complements full vapor smoothing processes for highly detailed prints.
Vapor-smoothed PETG is widely used in:
Vapor smoothing PETG improves both functional and aesthetic value, making it an essential tool for manufacturing and post-processing.
Effective PETG smoothing techniques include:
Each method requires protective equipment, safety precautions, and careful handling to avoid overexposure, which could warp 3D printed parts.
| Solvent | Suitable Filament | Exposure Method | Result | Safety Notes |
| MEK | PETG | Vapor container | Smooth and glossy | Respirator, gloves, well-ventilated area |
| Ethyl Acetate | PETG, PLA | Vapor bath/brush | Glossy, minor softening | PPE, ventilated workspace |
| Dichloromethane | PETG | Controlled vapor | Perfectly smooth | Highly hazardous, PPE mandatory |
| Acetone | ABS, ASA | Vapor bath | Layer line elimination, glossy | Flammable, ventilated space |
| Tetrahydrofuran | PLA, PETG | Vapor exposure | Smooth outer layer | Hazardous, PPE mandatory |
Post-processing can also highly benefit you with the use of vapor smoothing PETG which can take your 3D printed components to the next level of professionalism. It enhances the smoothness, glossiness and functionality of the surface whether of prototypes, consumer goods or industrial components.
The most important things to be considered regarding the success are the correct solvents used, safety precautions, and dimensional accuracy in the process of smoothing. Vapor smoothing can be applied to your PETG 3D prints with great care to make a significant improvement to the final quality.
Use MEK, ethyl acetate, or dichloromethane for vapor smoothing PETG. The vapor exposure process softens the surface to eliminate layer lines and create a glossy finish.
Vapor smoothing is a post-processing technique where solvent vapors dissolve the outer layer of a 3D print, allowing it to self-level and smooth out imperfections.
No, acetone doesn’t work well with PETG filament. Use MEK, ethyl acetate, or dichloromethane instead for effective results.
Yes, PETG can be heat treated, though it requires precise temperature control. Heat treatment can improve surface smoothness but doesn’t replace vapor smoothing.
Yes, PETG filament can be vapor smoothed using the right solvents like MEK or ethyl acetate. The technique creates a smooth surface without compromising dimensional accuracy.
Yes, vapor smoothing PETG is effective and works by softening the outer layer through controlled solvent vapor exposure, resulting in a glossy finish and smooth surface.
Vapor smoothing 3D prints involve exposing the print to solvent vapors to soften and dissolve the outer layer. This results in a smooth, glossy surface with no layer lines.
Vapor smoothing is a great solution for FFF 3D prints, especially with PETG and PLA filaments that have rough surfaces after printing.
Yes, vapor smoothing eliminates imperfections and layer lines, making the surface smooth and uniform, improving both aesthetic quality and functional performance.
While vapor smoothing improves adhesion between layers and enhances the outer surface, it doesn’t significantly affect the internal strength of PETG parts. However, interlayer adhesion is improved.
Laser Beam Profiling enhances vapor smoothing by measuring surface smoothness and uniformity, ensuring that the part’s final surface is consistent across its entire geometry.
The cost of vapor smoothing PETG varies depending on the solvents used and the setup. Typically, MEK and ethyl acetate are affordable solvents, while vapor smoothing equipment like ventilated chambers and safety equipment can add to costs.
Products include consumer electronics, medical devices, custom tooling, consumer goods, and prototypes.
PETG, PLA, ABS, and ASA filaments can all be vapor smoothed using the appropriate solvents for each material.
Chemical vapor smoothing or chemical vapor polishing are other names for the vapor smoothing process.
Unlike sanding and polishing, vapor smoothing works at the molecular level to create a smooth, glossy surface without removing material.
